SA 387 Grade 11 Class 1 and Class 2: One Steel, Two Strength Classes
SA 387 Grade 11 is a chromium molybdenum alloy steel plate specified in ASTM A387/A387M for welded pressure vessels and boilers operating at elevated temperature. The grade contains nominally 1.25 percent chromium and 0.50 percent molybdenum, a combination that provides good resistance to oxidation, hydrogen attack and creep at temperatures well above the range of carbon steel.
Class 1 and Class 2 are not different steels. The chemical composition and the heat treatment route are identical; both classes are normally supplied normalized and tempered. What changes is the tempering practice and the resulting mechanical property requirement, so the same heat of steel can be finished to either class depending on the strength level the vessel design demands.
The practical consequence is simple: Class 2 gives higher tensile and yield strength, while Class 1 gives better ductility and lower hardness, which simplifies welding and reduces the risk of cracking in thick sections.
Chemical Composition of SA 387 Grade 11
The composition range applies to both classes under ASTM A387/A387M.
| Element | Class 1 and Class 2, % | Function |
|---|---|---|
| Carbon (C) | 0.04-0.17 | Strength and hardenability; limited for toughness |
| Silicon (Si) | 0.44-0.86 | Deoxidation |
| Manganese (Mn) | 0.35-0.73 | Strength and deoxidation |
| Phosphorus (P) | 0.035 max | Impurity control |
| Sulfur (S) | 0.035 max | Impurity control |
| Chromium (Cr) | 0.94-1.56 | Oxidation and corrosion resistance at temperature |
| Molybdenum (Mo) | 0.40-0.70 | Creep strength and hydrogen resistance |
The nominal composition of 1.25Cr-0.5Mo places the grade alongside the comparable chromium molybdenum pressure vessel grades listed in European and Japanese standards, which is useful when a vessel is designed in one system and fabricated in another.
Mechanical Properties of Class 1 and Class 2
| Property | Class 1 | Class 2 |
|---|---|---|
| Minimum yield strength, t up to 50 mm | 240 MPa | 310 MPa |
| Tensile strength | 415-585 MPa | 515-690 MPa |
| Minimum elongation, t up to 50 mm | 22 % | 18 % |
| Minimum elongation, 50 mm < t up to 200 mm | 19 % | Specified for thinner ranges |
| Composition | Identical range for both classes | |
| Heat treatment | Normalized and tempered | Normalized and tempered, lower tempering temperature |
Class 2 properties are specified for plate thicknesses up to about 50 mm; heavier plate is usually ordered as Class 1 because the strength benefit of the higher class cannot be guaranteed through a thick section. The higher tensile range of Class 2 is obtained mainly by tempering at a lower temperature, which retains more of the strengthening from the normalizing treatment.
How the Classes Behave in Fabrication
Chromium molybdenum plate is more sensitive to welding than carbon steel. Both classes require a qualified welding procedure with preheating, controlled interpass temperature and hydrogen controlled consumables, and both normally require post weld heat treatment to relieve residual stress and temper the heat affected zone.
Higher hardness in the heat affected zone of Class 2 plate calls for stricter preheat and post weld heat treatment control.
Post weld heat treatment is carried out in the range generally used for 1.25Cr-0.5Mo steel, with time and temperature selected so that the base metal strength required by the class is retained.
Hardness checks on the weld and heat affected zone are common acceptance requirements, and lower strength Class 1 plate is easier to keep within typical limits.
Cold forming is limited because of the higher strength and lower ductility of Class 2, and formed parts benefit from a stress relief treatment after forming.
Applications and Selection
Class 1: boiler drums, heat exchanger shells, steam piping components and vessels where ductility, weldability and forming take priority.
Class 2: hydrocracker and hydrotreater reactors, high pressure separators and thick walled equipment where the design pressure calls for higher allowable stress.
Both classes: high temperature service in refinery, petrochemical and power plant equipment, including hydrogen containing streams where resistance to hydrogen attack matters.
Frequently Asked Questions
Q: Is the chemical composition different between Class 1 and Class 2?
No. ASTM A387/A387M specifies one composition range for Grade 11, and both classes are produced within it.
Q: What is the yield strength difference?
Class 1 requires a minimum of 240 MPa and Class 2 a minimum of 310 MPa for plate up to 50 mm thick, a difference of about 70 MPa.
Q: How is the higher strength of Class 2 achieved?
By tempering at a lower temperature after normalizing, which retains more strength; the steel itself is the same 1.25Cr-0.5Mo material.
Q: Which class is easier to weld?
Class 1, because its lower strength and hardness give more tolerance in preheat, heat input and post weld heat treatment control.
Q: Is post weld heat treatment required for both classes?
It is normally required for chromium molybdenum pressure vessel plate of both classes, and the procedure must be qualified for the strength class supplied.
Q: Why is Class 2 usually limited to thinner plate?
Through thickness quenching and tempering response make the higher strength level hard to guarantee in heavy sections, so thick plate is generally ordered as Class 1.
