A204 GradeA Molybednum Steel Plates
ASTM A204 boiler steel plate is a molybdenum alloy steel plate, which is mainly suitable for welding boilers and high temperature pressure vessels. According to the molybdenum content, ASTM A204 container steel plate is divided into 3 grades: A, B, C.
ASTM A204 Grade A belongs to alloy steel. Another common name for ASTM A204 Grade A alloy steel is UNS K11820. A204 Grade A chromium-molybdenum alloy steel is a molybdenum alloy steel material used to manufacture high temperature pressure vessels.
A204 grade a steel boiler plate chemical composition
| Grade | Thickness(mm) | C max | Mn max | P max | S max | Si max | Mo |
| SA204 Grade A | t≤25 | 0.18 | 0.90 | 0.025 | 0.025 | 0.15-0.40 | 0.45-0.60 |
| 25<t≤50 | 0.21 | ||||||
| 50<t≤100 | 0.23 | ||||||
| 100<t | 0.25 |
a204 grade a Boiler Plate Steel mechanical property
| Mechanical Property | A204 Grade A |
| Tensile strength, kis [MPa] | 65-85 [450-585] |
| Yield strength, min, kis [MPa] | 37 [255] |
| Elongation in 8 in. [200 mm], min, % | 19 |
| Elongation in 2 in. [50 mm], min, % | 23 |
a204 grade a pressure vessel steel plate Weight Chart
| Plates Thickness (mm) |
Weight (kg/m2) |
|---|---|
| 1.6 | 12.6 |
| 3 | 23.6 |
| 2.5 | 19.6 |
| 2.0 | 15.7 |
| 3.2 | 25.1 |
| 4 | 31.4 |
| 5 | 39.3 |
| 6 | 47.1 |
| 10 | 78.5 |
| 12.5 | 98.1 |
| 8 | 62.8 |
| 20 | 157 |
| 35 | 275 |
| 22.5 | 177 |
| 15 | 118 |
| 30 | 236 |
| 32 | 251 |
| 25 | 196 |
| 40 | 314 |
| 45 | 353 |
pressure vessel plate Products image
GNEE group team photo
GNEE group customer visit
GNEE Group steel exhibition
Our products have undergone strict quality inspections and are equipped with professional certificates. If you have any questions about A204 GradeA Molybednum Steel Plates, you are welcome to check.
