Name: Grade B Corten Steel Plate
Brand: GNEE
SKU: 230971934

Description

Technical Parameters

Grade B Corten Steel Plate

CortenB Corten steel introduction:Full name of atmospheric corrosion resistant high strength low alloy steel plate or called atmospheric corrosion resistant hot rolled steel plate, also known as Corten steel, corrosion-resistant steel is widely used in containers, power plants, chimneys, railway engineering and outdoor steel, with good corrosion and heat resistant properties, has good mechanical properties stamping and bending and other processability, has good plasticity.

corten b weathering steel sheet chemical composition

Grade Corten B	C	Si	Mn	P	S	Cr	Ni	Cu	Al	V
Grade Corten B	0.19 max	0.30 – 0.65	0.80 – 1.25	0.035 max	0.030 max	0.40 – 0.65	0.40 max	0.25 – 0.40	0.020 – 0.06	0.02 – 0.10

corten b corten steel sheet metal mechanical property

Grade	Yield strength ReL N/mm² Minimum	Tensile strength Rm N/mm² Minimum	Elongation A50% Minimum
Corten B	345	485	19

CortenB Corten Steel Technical Requirements

1, CortenB corten steel sheet size, shape, weight and allowable deviation should be in line with the provisions of GB709-88 standard.

2,CortenB corten steel panel surface quality: according to GB4172-84 regulations.

3,CortenB weathering steel sheet ultrasonic flaw detection: according to customer requirements wake ultrasonic flaw detection.

4, CortenB corten steel sheet metal chemical composition analysis allowable deviation: according to GB222 specifications implementation.

5,CortenB weathering steel sheets packaging, packaging, marking and quality certification according to GB247 specifications.

Uses of CortenB Corten steel

Cowden steel is mainly used for: gas saving, air preheaters, heat exchangers and evaporators in high sulphurous flue gases, to resist the condensation corrosion of sulphurous flue gases. It has the best resistance to sulfur ions, hydrochloric acid and other acidic corrosion. Spiral grooved tubes are the main, economical and proven heat transfer element and have been used in a large number of air preheater products for various boilers. The spiral groove tube utilizes the inner wall and the spiral groove to guide the flow, forcibly perturbing the work material inside the tube, thus improving the heat transfer efficiency. The heat transfer coefficient of spiral groove tube can generally reach 1.25 times of the same diameter light tube, the use of spiral groove tube can improve the efficiency of the heat exchange equipment, reduce the amount of steel pipe, reduce the space occupied by the heat exchange equipment, with good economy and reliability.
