LR Marine Plate Materials
"LR standard ship plate" refers to the ship construction standard of Lloyd's Register (LR). Lloyd's Register's rules and regulations establish appropriate standards for the design, construction and life-cycle maintenance of ships, offshore installations and land-based installations.
LR A B D E steel is a hot rolled ordinary tensile strength steel. Ordinary strength LR shipbuilding steel has 3 strengths and 12 grades, and A, B, D and E grades are some of them. The yield strength of LR grade A B D E steel plate is 235 MPa and the ultimate tensile strength is 400-520 MPa.
LR MTC
The grades of LR standard shipbuilding steel plates we can provide include
|
LR Steel Plate Grade Supplier |
||||
|
General Strength |
LR/A |
LR/B |
LR/D |
LR/E |
|
High Strength |
LR/AH32 |
LR/DH32 |
LR/EH32 |
LR/FH32 |
|
LR/AH36 |
LR/DH36 |
LR/EH36 |
LR/FH36 |
|
|
LR/AH40 |
LR/DH40 |
LR/EH40 |
LR/FH40 |
|
|
Extra Strength |
LR/AH42 |
LR/DH42 |
LR/EH42 |
LR/FH42 |
|
LR/AH46 |
LR/DH46 |
LR/EH46 |
LR/FH46 |
|
|
LR/AH50 |
LR/DH50 |
LR/EH50 |
LR/FH50 |
|
|
LR/AH55 |
LR/DH55 |
LR/EH55 |
LR/FH55 |
|
|
LR/AH62 |
LR/DH62 |
LR/EH62 |
LR/FH62 |
|
|
LR/AH69 |
LR/DH69 |
LR/EH69 |
LR/FH69 |
|
LR standards marine sheet chemical composition
| Steel grade | C | Si | Mn | P | S | Als |
| Grade A | ≤0.21 | ≤0.50 | ≥2.5C | ≤0.035 | ≤0.035 | - |
| Grade B | ≤0.21 | ≤0.35 | 0.8-1.2 | ≤0.035 | ≤0.035 | - |
| Grade D | ≤0.21 | ≤0.35 | 0.6-1.2 | ≤0.035 | ≤0.035 | ≥0.015 |
| Grade E | ≤0.18 | ≤0.35 | 0.7-1.2 | ≤0.035 | ≤0.035 | ≥0.015 |
LR standards metal used in shipbuilding mechanical property
| Steel grade | Yield point/MPa | Tensile point /MPa | Elongation/% | Temperature/° C | V-type impact test | ||
| Akv/J | |||||||
| ≤50MM | 50-70MM | 70-100MM | |||||
| Grade A | 235 | 400-520 | ≥22 | 20 | - | 34/24 | 41/27 |
| Grade B | 235 | 400-520 | ≥22 | 0 | 27/20 | 34/24 | 41/27 |
| Grade D | 235 | 400-520 | ≥22 | -20 | 27/20 | 34/24 | 41/27 |
| Grade E | 235 | 400-520 | ≥22 | -40 | 27/20 | 34/24 | 41/27 |
Our services regarding LR standards Marine shipbuilding plates
1. Accurate quotation of LR standard marine slab floor to reduce procurement costs for you.
2. Timely communication allows you to monitor the entire production process and progress.
3. The superior quality of LR standard marine plates enables you to pass steel inspection and monitor finished product quality.
4. Considerable transportation can help you reduce transportation costs and let you know the transportation situation at any time.
5. Quality assurance, allowing you to get the original factory warranty as soon as possible, allowing you to smoothly carry out the next production and work plan.
6. LR Standard Ship steel plate high-quality after-sales service helps you get invoices as soon as possible and provides advice and support on billing management.
7. Tracking services and feedback from steel mills make our services more considerate.
Key Advantages of LR Marine Steel Plate
Extreme Environments and Full Lifespan Durability
The LR rules impose extremely stringent requirements for extreme operating conditions such as polar regions and deep sea, delivering maximum safety redundancy for high-risk scenarios.
Polar Icebreaking Sector: LR stipulates that vessels with Ice Class 1A Super must be equipped with double-way icebreaking capacity, and their steel plates are required to pass impact tests at -50℃, while standards including ABS generally have no such low-temperature requirements. Since 2020, 65% of Arctic LNG shipping projects have prioritized LR-certified steel plates.
Cryogenic Cargo Materials: In the LNG carrier sector, LR mandates the adoption of 9% nickel steel to withstand ultra-low temperatures of -163℃. In contrast, DNV permits alternative alloys with a nickel content of only 5%, which show relatively insufficient long-term durability.
Long-term Corrosion Protection: LR requires ballast tank coatings to withstand a minimum of 1,000 hours of ASTM B117 salt spray testing, achieving 15 years of hull protection, with durability notably improved compared to DNV's 10-year standard. Throughout the full lifecycle, vessels certified by LR can achieve a 15% enhancement in overall corrosion resistance.
Refined High-strength and Ultra-tough Material Database
For large-scale and lightweight ships and marine engineering equipment, LR offers an extensive range of high-end and rigorous strength grades.
Strength Coverage: LR-certified steel plates cover strength grades from conventional levels (yield strength of 235MPa) to ultra-high strength grades with a yield strength of 690MPa (e.g., FH69).
High-strength Steel Performance Example - LR EH46: Taking EH46, the benchmark grade of ultra-high strength and toughness marine steel, as an example, it features a yield strength of ≥460 MPa (tensile strength: 570-720 MPa), and delivers a longitudinal impact energy of up to 46 J in polar environments at -40℃. Meanwhile, its carbon equivalent is precisely controlled (C ≤ 0.20%), ensuring excellent cold bending and welding performance.
Equivalent Grades Comparison
| LR Grade | ABS Grade | ASTM Equivalent | EN Equivalent | CCS Equivalent |
|---|---|---|---|---|
| LR A | ABS A | ASTM A131 A | S235JR | CCS A |
| LR AH36 | ABS AH36 | ASTM A131 AH36 | S355 | CCS AH36 |
| LR DH36 | ABS DH36 | ASTM A131 DH36 | S355 | CCS DH36 |
| LR EH36 | ABS EH36 | ASTM A131 EH36 | S355 | CCS EH36 |
ABS A VS LR A
ABS A and LR A are both general-strength hull structural steels, with a minimum yield strength of 235 MPa and a tensile strength ranging from 400 MPa to 520 MPa. In comparison, LR A has a slightly higher upper tensile limit at 58,000 – 75,500 psi, which corresponds to 400–520 MPa. Although their conventional mechanical properties appear identical, the critical differences lie in the following three aspects, which directly influence material selection and overall project costs:
Rigour of Inspection and Acceptance
This is the most essential distinction. For Grade A applications (ambient temperature, non-toughness critical), LR certification imposes far stricter control over the internal quality of steel plates. Compared with CCS and ABS, LR surveyors are more likely to require on-site witnessed inspections and issue more detailed, stringent inspection documentation.
Target Markets (Shipowners & Shipyards)
The end market of a project determines the required classification certificate.
LR A: Serves as a standard qualification for high-end European markets - especially the UK and Commonwealth regions - premium international shipowners, cruise vessels, and Ro-Ro ships, and is widely preferred by high-end global operators.
ABS A: Remains the mainstream option for the United States, the Americas, South Korea, the Middle East, and general international cargo vessels. It is also commonly specified and accepted by Korean and American shipyards.
Comprehensive Cost & Lead Time Impac
Due to stricter certification standards and more complex approval procedures, LR A steel plates generally carry higher procurement costs than ABS A. Its delivery cycle is also more prone to delays caused by mill production scheduling and mandatory surveyor witnessing. It is recommended to verify the shipyard's existing Welding Procedure Specifications (WPS) in advance to avoid recertification requirements when switching classification societies, which would incur extra time and financial expenses.
FAQ – LR Marine Plate Materials & ABS Marine Steel Plate
What is the main practical difference between LR Grade A and ABS Grade A steel plates?
While both require a minimum yield strength of 235 MPa and tensile strength of 400–520 MPa, the key difference lies in certification rigor. LR Grade A typically demands stricter on-site witness testing by the surveyor and tighter control over batch-to-batch property variation, which provides higher reliability for critical structural applications.
What low-temperature toughness does LR Grade E guarantee?
A: LR Grade E guarantees a minimum Charpy V-notch impact energy of 27 J at -40°C, witnessed by the surveyor. This makes it suitable for structures operating in cold climates and ice waters.
For high-strength LR EH36, what tensile properties and impact temperature apply?
LR EH36 has a minimum yield of 355 MPa, tensile strength of 490–630 MPa, and requires impact testing at -40°C. The combination of high strength and low-temperature toughness is essential for large vessel hulls.
Are there specific carbon equivalent limits for LR high-strength plates to ensure weldability?
A: Yes. For grades like EH36, the carbon equivalent (Ceq) is typically controlled ≤0.38–0.40% and the cold-cracking susceptibility index (Pcm) is limited, reducing preheat requirements and avoiding hydrogen-induced cracking.
How does LR certification rigour differ from DNV for offshore-grade plates?
A: For critical applications, LR more often mandates surveyor-witnessed tensile and impact testing and full traceability, while DNV may accept mill-certified results for some standard grades. This makes LR certification a stronger quality assurance signal for end buyers.
Why Choose GNEE STEEL?
- Extensive experience in marine steel export
- Full range of LR & ABS certified plates
- Competitive factory pricing
- Strict quality control and certification support
- Custom processing services (cutting, drilling, welding)
- Reliable delivery worldwide
Conclusion
LR Marine Plate Materials and ABS Marine Steel Plate are essential for safe, durable, and high-performance marine structures. With similar mechanical properties and global acceptance, they provide flexible solutions for shipbuilding and offshore projects.
Looking for a trusted supplier of LR and ABS marine steel plates?
GNEE STEEL offers:
- Wide grade selection (A, AH32, AH36, DH36, EH36)
- Custom sizes and fast delivery
- Competitive global pricing
👉 Contact us now with your project details (grade, size, quantity) and receive a professional quotation within 24 hours!
