ASTM A662 Carbon Boiler Plate

ASTM A662 carbon boiler plate Grade A/B/C is a normalized carbon-manganese steel plate designed for use in boilers and pressure vessels operating at moderate temperatures. With enhanced notch toughness, improved ductility, and excellent weldability, ASTM A662 is widely used in critical equipment across oil & gas, petrochemical, and power industries.



As a professional exporter, GNEE Steel supplies high-quality ASTM A662 boiler plates with full certification, strict quality control, and reliable global delivery.





ASTM A662 carbon boiler plate is a kind of carbon-manganese-silicon steel plate formulated by ASTM International, mainly designed for welded pressure vessels that require improved low-temperature notch toughness.



As a professional ASTM A662 supplier with 18 years of experience, GNEE provides three grades (Grade A, Grade B, Grade C) of this boiler plate, which are widely used in moderate and low-temperature service scenarios such as energy, chemical, electric power and water conservancy industries.



Our ASTM A662 carbon boiler plate fully complies with ASTM A662/A662M-17 standard, with strict quality control and stable performance, perfectly meeting the needs of global customers for high-reliability pressure vessel materials.



Available Grades:

• ASTM A662 Grade A
• ASTM A662 Grade B
• ASTM A662 Grade C

Grade C offers the highest strength among the three grades.





Chemical Composition (%)	ASTM A662 Grade A	ASTM A662 Grade B	ASTM A662 Grade C	Standard
Carbon (C)	≤0.17	≤0.22	≤0.24	ASTM A662/A662M-17
Silicon (Si)	0.13-0.45	0.13-0.45	0.13-0.55
Manganese (Mn)	0.84-1.46	0.79-1.62	0.92-1.72
Phosphorus (P)	≤0.035	≤0.035	≤0.035
Sulfur (S)	≤0.035	≤0.035	≤0.035





Mechanical Properties	ASTM A662 Grade A	ASTM A662 Grade B	ASTM A662 Grade C	Note
Yield Strength (Min, MPa)	275 (6-50mm); 275 (50-200mm)	275 (6-50mm); 275 (50-200mm)	295 (6-50mm); 295 (50-200mm)	Thickness-dependent
Tensile Strength (MPa)	400-540	450-585	480-620	-
Elongation (Min, %)	23 (6-50mm); 20 (50-200mm)	23 (6-50mm); 20 (50-200mm)	22 (6-50mm); 18 (50-200mm)	Thickness-dependent
Delivery Status	Hot rolled (≤40mm); Normalized (＞40mm, mandatory); Stress relieved (optional)			-
Thickness Range	6-200mm (max thickness limited by mechanical property requirements)			-
Equivalent Grade	EN 10028-P290; JIS G3115-SPV235	EN 10028-P295GH; JIS G3115-SPV245	EN 10028-P315; JIS G3115-SGV315	International equivalent





Superior Low-Temperature Toughness: The plate maintains excellent impact toughness even in -40℃ to -45℃ environment (impact energy ≥27J), effectively preventing brittle fracture and adapting to extreme cold working conditions. It is especially suitable for low-temperature pressure vessels such as liquefied gas storage tanks.



High Strength & Stability: Different grades have corresponding mechanical properties. For example, Grade C has a yield strength of ≥295MPa and a tensile strength of 480-620MPa (when thickness ≤50mm), which can stably bear high pressure and meet the structural support requirements of boiler drums and pressure vessels.



Excellent Weldability & Processability: The carbon equivalent is reasonably controlled, supporting shielded metal arc welding, gas metal arc welding, submerged arc welding and other processes. The welding joint has high strength and good air tightness. It is easy to cut, form and process, and can be customized into complex shapes according to customer needs.



Strict Quality Control: Adopts electric arc furnace or basic oxygen furnace smelting, combined with ladle refining technology, strictly controlling harmful elements such as phosphorus (P≤0.035%) and sulfur (S≤0.035%) to ensure the purity of steel plates. All products pass ultrasonic flaw detection (ASTM A435/A577) and other tests to ensure no internal defects.



Customization & Timely Supply: We provide customized services for thickness (6-200mm), width, length and processing (cutting, drilling, surface treatment), and have sufficient inventory to meet the urgent needs of customers. Our sales network covers more than 200 countries, ensuring timely delivery worldwide.





ASTM A662 carbon boiler plate is widely used in industries that require high toughness, high strength and low-temperature resistance, especially suitable for welded pressure vessels and boiler components. Its main application scenarios include:



Energy & Chemical Industry

Nuclear energy equipment (reactor pressure vessel, boiler drum), low-temperature storage tanks (liquefied gas spherical tank), petrochemical reactors, separators and heat exchangers, which can adapt to high pressure, low temperature and corrosive working conditions.



Electric Power & Water Conservancy

Power station boiler drum structural parts, hydropower station high-pressure water pipes and water turbine volutes, which can bear water pressure impact and ensure the stable operation of power and water conservancy equipment.



Other Fields

Oil and gas storage and transportation equipment (oil and gas tanks, liquefied petroleum gas cylinders), food industry pressure vessels, and other low-temperature and medium-pressure equipment components that require high reliability.





Grade	Key Feature	Application
ASTM A662	Normalized, improved toughness	Boilers & vessels
ASTM A285	Lower strength, basic applications	Low-pressure tanks
ASTM A516	Higher strength & toughness	Medium-pressure vessels

ASTM A662 offers a middle-ground solution between A285 and A516 in terms of strength and toughness.





Standard	Equivalent Grade	Description
EN (Europe)	P295GH	Pressure vessel steel with similar strength
DIN (Germany)	1.0481 / HII	Boiler steel with good toughness
JIS (Japan)	SB480	Boiler and pressure vessel steel
GB (China)	Q345R / 16MnR	Pressure vessel steel widely used in China

Notes:

Exact equivalence depends on heat treatment and impact requirements

ASTM A662 is typically supplied in normalized condition, similar to EN P295GH





Smelting: Adopt electric arc furnace (EAF) or basic oxygen furnace (BOF) smelting process, combined with ladle refining (LF) technology, strictly control the content of harmful impurities, and ensure the uniformity and purity of chemical composition.



Rolling: Apply controlled rolling and controlled cooling (CRCC) technology, heat the billet to 1100-1250℃ for hot rolling, and precisely control rolling speed, pressure and cooling rate to improve grain refinement and surface quality.



Heat Treatment: Take normalizing heat treatment as the core, heat the steel plate to 890-950℃ for heat preservation, then cool it in air to optimize the microstructure, eliminate internal stress and improve low-temperature toughness.



Inspection: Conduct strict quality inspection, including chemical composition analysis, mechanical property test (tensile, impact, bending), ultrasonic flaw detection (ASTM A435/A577), and other tests to ensure that each batch of products meets the standard requirements.



Processing & Packaging: Provide customized processing such as laser cutting, flame cutting and drilling according to customer needs; adopt standard seaworthy packaging to prevent corrosion during transportation and ensure the integrity of products.





What is the ASTM A662 equivalent to?

ASTM A662 equivalents include European standards like EN 10028-2 and JIS standards, with specific grade matches such as P275NL1 for A662 Grade A, P295GH or P290 for A662 Grade B, and P355NH or SGV315 for A662 Grade C.



What is ASTM A662 steel used for?

It is used for boilers and pressure vessels operating at moderate temperatures.



What grades are available?

Grade A, Grade B, and Grade C.



Which grade is strongest?

Grade C has the highest strength.



 Is ASTM A662 heat treated?

Yes, it is supplied in normalized condition.



What is the advantage of ASTM A662?

Better toughness than A285 with good cost-performance balance.



Can ASTM A662 be welded?

Yes, it has excellent weldability.



What industries use ASTM A662?

Oil & gas, petrochemical, power plants, and manufacturing.



What is the equivalent EN grade?

P295GH is commonly used as a reference.



What thickness is available?

Typically 6mm to 150mm.



Does GNEE provide export services?

Yes, we provide full export support and documentation.



What is the difference between ASTM A662 Grade A, B and C?

The main difference lies in the manganese content and mechanical properties. The manganese content increases from Grade A to Grade C, which leads to the gradual improvement of tensile strength and yield strength. Grade C has the highest strength and is suitable for more demanding low-temperature and high-pressure scenarios.



Can GNEE provide customized thickness and size for ASTM A662 carbon boiler plate?

Yes. We support customized services for thickness (6-200mm), width (1250-4200mm) and length (3000-27000mm). We can also provide cutting, drilling, surface shot blasting and other processing according to your drawings and requirements.



What is the delivery time of ASTM A662 carbon boiler plate?

For spot products, the delivery time is 3-7 working days; for customized products, the delivery time is 15-30 working days, depending on the order quantity and processing requirements. We have sufficient inventory to ensure timely delivery to global customers.



Does ASTM A662 carbon boiler plate meet the export standards of European and American markets?

Yes. Our products fully comply with ASTM A662A662M-17 standard, and have passed ISO, SGS and other certifications. They have been exported to the United States, Canada, Spain, Singapore and other countries, and fully meet the local import standards and usage requirements.



How to solve the welding problem of ASTM A662 carbon boiler plate?

The plate has excellent weldability. It is recommended to preheat to 50-100℃ before welding (preheat to ≥150℃ when thickness ＞30mm), control the heat input to ≤45 kJ/cm, and perform post-weld stress relief annealing to eliminate residual stress and ensure the reliability of the welding joint.





Petrochemical Customer in Mexico Customer Demand: Need ASTM A662 Grade C carbon boiler plate with thickness 20mm, used for manufacturing low-temperature liquefied gas storage tanks, requiring -40℃ impact toughness and ultrasonic flaw detection Grade II.



GNEE Solution: Customized production according to customer requirements, strictly controlling the manganese content and heat treatment process, providing free sample testing, and completing delivery within 18 working days.



Cooperation Feedback: The product performance is stable, fully meeting the requirements of low-temperature service, and has established long-term cooperative relations.
