What Is S690 Grade Steel?

S690 is the designation for a high yield, fine grain structural steel supplied in the quenched and tempered condition. The name is read directly from the European designation system: "S" stands for structural steel, "690" is the minimum yield strength in megapascals. S690 steel plate is produced to EN 10025-6, the part of the European standard that covers flat products of high yield strength structural steels in the quenched and tempered condition. Because the plates are quenched and tempered rather than normalized or thermo-mechanically rolled, they combine a very high yield strength with a fine, uniform grain structure and usable toughness.

The grade is chosen for structures that must carry very heavy loads and for designs in which weight saving is a decisive factor. A high strength-to-self-weight ratio makes it efficient in heavily loaded members such as piles and columns in buildings, supporting members in bridges, and the load-bearing structures of cranes and heavy construction equipment.

The EN 10025-6 S690 Sub-Grades

Three sub-grades are defined within the S690 group, and the difference between them is the guaranteed impact toughness level. The quality designations use the letters Q and L, where Q denotes quenched and tempered delivery and L indicates an enhanced low-temperature impact requirement.

Sub-grade Standard Minimum yield strength Impact test condition
S690Q EN 10025-6 690 MPa Charpy test at -20 C
S690QL EN 10025-6 690 MPa Charpy test at -40 C
S690QL1 EN 10025-6 690 MPa Charpy test at -60 C

The three sub-grades share the same strength requirement and the same general chemical basis; selecting between them is essentially a question of service temperature and of the fracture toughness the design case demands. The same standard also defines the higher strength S890 and S960 groups for applications where 690 MPa is not sufficient.

Approximate Equivalent Grades

Designers who work with more than one national system often need a cross-reference. The following grades are approximately equivalent in strength level, but each is governed by its own standard and its own property set, so equivalence is for orientation only and contract documents should always name the governing grade.

ASTM A514 quenched and tempered alloy steel plate

EN 10149-2 Grade S700MC thermo-mechanically rolled steel

AS/NZS 3579 Grade 700 quenched and tempered steel plate

GB/T 16270 Q690 series quenched and tempered plate

EN 10025-6 S890QL and S960QL for higher strength requirements

The distinction that matters most in practice is the delivery condition. A thermo-mechanically rolled grade such as S700MC derives its properties from controlled rolling, whereas S690QL is quenched and tempered; the two are not freely interchangeable in a welded design without a fresh procedure qualification.

Mechanical and Physical Behaviour

The defining property of S690 grade steel is a minimum yield strength of 690 MPa, roughly double that of ordinary S355 structural steel. High strength plates are sensitive to the yield-to-tensile ratio and to ductility, so the specification also sets a tensile strength range and a minimum elongation, and it requires the notch toughness to be verified by Charpy V-notch testing at the temperature corresponding to the sub-grade.

The material is also characterized by a low carbon equivalent in comparison with conventional carbon-manganese steels of similar strength, which keeps weldability workable when the appropriate consumables, heat input and preheat are used. Quenched and tempered plate nevertheless needs controlled fabrication practice: bending radii are generous, thermal cutting edges may need dressing before welding, and post-weld heat treatment must stay within the temperature limits agreed for the grade.

Where S690 Grade Steel Is Used

Piles, columns and transfer members in building structures

Supporting members and heavily loaded sections in bridges

Offshore drilling rig structures and heavy lifting frames

Cranes, excavators and other heavy construction equipment

Load-bearing components in haulage and transport equipment

In all these applications the grade allows sections to be slimmed down, which reduces dead load, foundation size and transport cost. The benefit is largest in mobile structures, where every kilogram of steel removed from the structure also reduces the load the machine has to move.

Frequently Asked Questions

Q: What does S690 mean?
In the European designation system, S stands for structural steel and 690 is the minimum yield strength in megapascals.

Q: Which standard covers S690 grade steel plate?
S690 plates are specified to EN 10025-6, which covers high yield strength structural steels in the quenched and tempered condition.

Q: What is the difference between S690Q, S690QL and S690QL1?
All three have a minimum yield strength of 690 MPa; they differ in the guaranteed Charpy impact test temperature, which is -20 C for S690Q, -40 C for S690QL and -60 C for S690QL1.

Q: What is the equivalent of S690 steel?
Approximate equivalents include ASTM A514, EN 10149-2 Grade S700MC, AS/NZS 3579 Grade 700 and the GB/T 16270 Q690 series, although each is governed by its own standard.

Q: What is the yield strength of S690 steel?
The minimum yield strength is 690 MPa, which is why the grade is used in structures that carry extremely heavy loads.

Q: Is S690 steel easy to weld?
It is weldable when qualified procedures are followed, using matched consumables and controlled heat input, preheat and interpass temperature.

Q: Where is S690 steel typically used?
Typical uses are piles and columns in buildings, supporting members in bridges, offshore rig structures, cranes and heavy construction equipment.
