C Channel Steel A36
A36 hot-rolled C-sections, also known as "American Standard Channels," are the best choice for most processing techniques. A36 hot rolled channel steel has a rough blue-gray surface. The A36 material is a mild steel that is long-lasting and durable. Hot-rolled C-sections have a "structural shape" that is, at least one dimension (not including length) is greater than 3 inches. C-channels have an approximately 16-2/3% slope within the flange face, unlike "MC" channels. Common applications include structural supports, trailers and other construction uses. ASTM A36/A36M-08 is the standard specification for carbon structural steel.
a36 channel steel beam chemical composition
| Steel grade | Styles | Carbon, max, % | Manganese, % | Phosphorus, max, % | Sulfur, max, % | Silicon, % |
|---|---|---|---|---|---|---|
| A36 | Steel shapes | 0.26 | -- | 0.04 | 0.05 | ≤0.40 |
a36 c channel steel mechanical property
| Steel grade | Styles | Tensile strength, ksi [MPa] | Yield point, min, ksi [MPa] | Elongation in 8 in. [200 mm], min, % | Elongation in 2 in. [50 mm], min, % |
|---|---|---|---|---|---|
| A36 | Steel shapes | 58 - 80 [400 - 550] | 36 [250] | 20 | 21 |
a36 U channel metal sizes
| Item | Depth (mm) | Flange width (mm) | Web thickness (mm) | Flange thickness (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| UPN80 | 80 | 45 | 6 | 8 | 8.64 |
| UPN100 | 100 | 50 | 6 | 8.5 | 10.6 |
| UPN120 | 120 | 55 | 7 | 9 | 13.4 |
| UPN140 | 140 | 60 | 7 | 10 | 16 |
| UPN160 | 160 | 65 | 7.5 | 10.5 | 18.8 |
| UPN180 | 180 | 70 | 8 | 11 | 22 |
| UPN200 | 200 | 75 | 8.5 | 11.5 | 25.3 |
a36 c section steel sizes
| Item | Depth (mm) | Flange width (mm) | Web thickness (mm) | Flange thickness (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| UPE80 | 80 | 40 | 4.5 | 7.4 | 7.05 |
| UPE100 | 100 | 46 | 4.5 | 7.6 | 8.59 |
| UPE120 | 120 | 52 | 4.8 | 7.8 | 10.4 |
| UPE140 | 140 | 58 | 4.9 | 8.1 | 12.3 |
| UPE160 | 160 | 64 | 5 | 8.4 | 14.2 |
| UPE180 | 180 | 70 | 5.1 | 8.7 | 16.3 |
| UPE200 | 200 | 76 | 5.2 | 9 | 18.4 |
a36 c section steel beams Products image
gNEE group team photo
GNEE group customer visit
We have professional online service personnel. If you have any questions about C Channel Steel A36, please send us an inquiry and we will reply to you within one working day.
