EN10025-6 S960Q High Tensile Steel Sheet is an ultra-high-strength structural steel produced through quenching and tempering (Q&T). With a minimum yield strength of 960 MPa, S960Q is designed for applications where extreme strength, reduced weight, and high performance are critical.
GNEE Steel supplies premium S960Q steel sheets and plates with reliable quality, full certification, and customized solutions for global engineering projects.
What is EN10025-6 S960Q High Tensile Steel Sheet?
S960Q is part of the EN10025-6 standard for high-strength structural steels. The "S" stands for structural steel, "960" refers to the minimum yield strength (960 MPa), and "Q" indicates quenched and tempered delivery condition.
Key Features:
- Ultra-high yield strength (≥ 960 MPa)
- Excellent strength-to-weight ratio
- Good weldability (with controlled procedures)
- Superior toughness under dynamic loads
- Suitable for extreme structural conditions
low alloy steel plate Chemical property
| C | Si | Mn | P | S | B | Cr | Cu | Mo | Nb | Ni | Ti |
| 0.22 | 0.86 | 1.8 | 0.03 | 0.017 | 0.006 | 1.6 | 0.55 | 0.74 | 0.07 | 2.1 | 0.07 |
high strength steel mechanical property
| Yield strength (Mpa) | Tensile strength (Mpa) | Elongation % | |||||||||||
| TH(MM) | >3≤50 | >50≤100 | >100≤150 | >3 ≤50 | >50≤100 | >100≤150 | 10 | ||||||
| 960 | - | - | 980-1150 | - | |||||||||
Advantages of S960Q High Tensile Steel Sheet
1. Extreme Strength Performance
S960Q offers one of the highest strength levels in structural steels, ideal for critical load-bearing applications.
2. Lightweight Design
High strength allows thinner sections, reducing total structure weight and transportation costs.
3. Excellent Structural Efficiency
Enables optimized design with fewer materials while maintaining safety and reliability.
4. Good Toughness
Maintains performance under impact and low-temperature environments.
5. High Fatigue Resistance
Suitable for dynamic and cyclic loading conditions.
Applications of EN10025-6 S960Q Steel Sheet
S960Q is widely used in industries requiring extreme strength:
- Heavy lifting equipment (cranes, boom arms)
- Mining and construction machinery
- High-performance structural components
- Offshore and energy sector equipment
- Military and specialized vehicles
Equivalent Grades of S960Q Steel
| Standard | Equivalent Grade |
|---|---|
| ASTM | A514 / A517 |
| GB | Q960E |
| JIS | HT950 / HT980 |
These equivalents offer similar ultra-high strength properties across different standards.
S960Q vs Other High-Strength Steel Grades
Comparison Within EN Standards
| Property / Grade | S690Q | S890Q | S960Q |
|---|---|---|---|
| Yield Strength | ≥ 690 MPa | ≥ 890 MPa | ≥ 960 MPa |
| Tensile Strength | 770–940 MPa | 940–1100 MPa | 980–1150 MPa |
| Strength Level | High | Very High | Ultra High |
| Application | Structures | Heavy equipment | Extreme engineering |
Equivalent Grade Comparison
| Property / Grade | S960Q | A514 | Q960E |
|---|---|---|---|
| Yield Strength | ≥ 960 MPa | ≥ 690 MPa | ≥ 960 MPa |
| Standard | EN | ASTM | GB |
| Heat Treatment | Q&T | Q&T | Q&T |
| Application | Advanced structures | Heavy equipment | High-strength machinery |
FAQ – EN10025-6 S960Q High Tensile Steel Sheet
What is S960Q steel mainly used for?
S960Q is used in ultra-high strength structural applications such as cranes, heavy machinery, and offshore equipment.
Is S960Q difficult to weld?
S960Q can be welded, but it requires:
- Preheating
- Controlled heat input
- Proper filler materials
Professional welding procedures are recommended.
What is the difference between S960Q and S690Q?
S960Q has significantly higher strength, allowing for lighter designs but requiring stricter processing control.
Does S960Q require heat treatment after delivery?
No, it is delivered in quenched and tempered condition, ready for fabrication.
Can S960Q be used in low temperatures?
Yes, it offers good impact toughness, especially when specified with additional testing requirements.
What thickness range can GNEE supply?
Thickness: 3mm – 150mm
Width: up to 3500mm
Length: up to 18000mm
Is S960Q more expensive than S690Q?
Yes, but it reduces material usage and improves performance, making it cost-effective overall.
What industries benefit most from S960Q?
Construction, mining, energy, transportation, and heavy equipment industries.
Why choose GNEE Steel for S960Q?
- Stable high-quality supply
- Advanced processing capability
- Fast delivery
- Rich export experience
Why Choose GNEE Steel?
Full quality control from raw material to delivery
Custom cutting, drilling, and machining services
Competitive pricing with reliable lead times
Strong technical support for global projects
Conclusion
EN10025-6 S960Q High Tensile Steel Sheet is a top-tier material for projects requiring extreme strength, durability, and efficiency. Its superior performance makes it indispensable in modern heavy engineering.
Looking for a trusted supplier of S960Q High Tensile Steel Sheet?
GNEE Steel provides:
- Premium quality steel
- Fast global delivery
- Professional support
👉 Send your inquiry today and receive a fast quotation with technical guidance!
